Model |
Center insertion loss (dB) |
BW1dB (MHz) |
Out-of-band attenuation (dB) |
Chip size (mm) |
|
4CBBP32R5-41R5-S1 |
2.0 |
32.5-41.5 | ≥40dB@21&49.5MHz | 14×9×4 |
|
6CBBP400-678-S1 |
1.0 |
400-678 | ≥40dB@330&820MHz | 14×9×4 |
|
6CBBP950-1280-S1 |
1.5 |
950-1280 | ≥40dB@815&1390MHz | 14×9×4 |
|
9CBLP700-S1 |
1.5 |
DC-700 |
≥40dB@785MHz |
14×9×4 |
|
6CBBP100-280-S1 |
1.5 |
100-280 | ≥40dB@10&370MHz | 14×9×4 |
|
6CBBP220-400-S1 |
1.5 |
220-400 | ≥40dB@130&490MHz | 14×9×4 |
|
6CBBP340-660-S1 |
1.5 |
340-660 | ≥40dB@180&820MHz | 14×9×4 |
|
6CBBP600-1020-S1 |
1.5 |
600-1020 | ≥40dB@390&1230MHz | 14×9×4 |
|
6CBBP1025-1475-S1 |
1.5 |
1025-1475 | ≥40dB@800&1700MHz | 14×9×4 |
|
4CBBP75U50-S1 |
1.0 |
50-100 | ≥40dB@22&128MHz | 14×9×4 |
|
6CBBP200U200-S1 |
1.0 |
100-300 | ≥40dB@25&420MHz | 14×9×4 |
|
6CBBP475U350-S1 |
1.0 |
300-650 | ≥40dB@125&825MHz | 14×9×4 |
|
6CBBP800U400-S1 |
1.5 |
600-1000 | ≥40dB@380&1200MHz | 14×9×4 |
|
4CBLP100-S1 |
1.5 |
DC-100 |
≥40dB@200MHz |
14×9×4 |
|
6CBBP750U600-S1 |
1.5 |
450-1050 | ≥40dB@150&1350MHz | 14×9×4 |
|
7CBLP2000-S1 |
1.5 |
DC-2000 |
≥30dB@2600MHz |
14×9×4 |
|
7CBHP800-S1 |
1.5 |
800-2300 |
≥40dB@350MHz |
14×9×4 |
|
6CBBP114-136-S1 |
2.0 |
114-136 | ≥40dB@88&155MHz | 14×9×4 |
