Power divider

Power divider Featured Image
  • Power divider

MYMMIC introduce both MMIC bare die , High-K thin Film Power divider which provide small size and very limited performance variation vs temperature,  as regards
to the Thin Film Power divider , MYMMIC is willing to customize the design for customer without NRE charge while proceed Fastest delivery, it is very competitive against the competitors ,the wide band performance is easy of integration and of a premium and quality Signal Splitting or Combine application is required.


Download as PDF

General Specifications

Product Tags

Model Freq Range Insertion Loss(dB) Insertion loss flatness(dB) VSWR Isolation(dB)
GaPD0R35/2V

0.35-2

1

 ±0. 2 1.6/1.3 13
GaPD0R5/1R5

0.5-1.5

0.9

 ±0. 2 1.4/1.4 20
GaPD0R5/1R5V

0.5-1.5

0.8

 ±0. 2 1.3/1.3 20
GaPD0R8/2

0.8-2.0

0.7

 ±0. 1 1.5/1.4 12
GaPD1/3

1.0-3.0

0.8

 ±0. 25 1.4/1.4 20
GaPD1/3V

1.0-3.0

0.8

 ±0. 2 1.5/1.5 18
GaPD2/6

2.0-6.0

0.7

 ±0.2 1.5/1.3 17
GaPD2/6V

2.0-6.0

0.7

 ±0.2 1.3/1.2 20
GaPD2/8-2T

1-8

 1.8 - 1.5/1.5 15
GaPD3/9

3.0-9.0

 0.7 ±0. 2 1.4/1.3 20
GaPD3/9V

3.0-9.0

 0.8 ±0. 2 1.4/1.3 20
GaPD2/18-2TA 2-18 1.0 ±0. 2 1.7/1.5 15
GaPD6/18 6-18 0.6 ±0. 15 1.5/1.3 17
GaPD6/18V 6-18 0.8 ±0. 4 1.3/1.4 20
GaPD8/12 8-12 0.4 ±0. 05 1.3/1.1 18
GaPD8/12V 8-12 0.5 ±0.1 1.4/1.2 16
GaPD12/18

12-18

 0.5 ±0. 2 1.4/1.1 20
GaPD18/26

18-26

 0.6 ±0.1 1.4/1.1 18
GaPD18/26V 18-26 0.7 ±0. 2 1.2/1.4 22
GaPD12/26R5 12-26.5 0.7 ±0. 2 1.4/1.5 20
GaPD20/40-3T

20-40

 0.7 - 1.5/1.3 20
GaPD18/40

18-40

 0.6 ±0.1 1.4/1.4 11
GaPD18/40V 18-40 0.8 ±0. 2 1.2/1.1 25
GaPD26/31V 26-31 0.7 ±0. 2 1.3/1.2 24
GaPD26/40 26-40 0.5 ±0.15 1.4/1.1 13
